Torque is a fundamental concept in physics that explains how forces cause objects to rotate. It is essential for understanding rotational motion, like how force is crucial for linear motion. Mastering it is important for AP® Physics 1 success, as it helps solve problems involving objects that pivot around an axis.
What We Review
What is Torque?
Torque is like a twist or a turning force. Imagine trying to open a door. A push near the hinges requires a lot more force to open the door than a push far from the hinges. This is due to torque or ( \tau ). It is calculated by multiplying the force ( F ) applied to an object and the distance ( r ) from the pivot point where the force is applied. Simply, it measures how effectively a force can rotate an object.
Real-world example: Think of using a wrench to tighten a bolt. The longer the wrench handle, the greater the torque, making it easier to turn the bolt.
The Torque Equation
The torque equation is a central part of understanding how torque works. It is expressed as:
\tau = r \cdot F \cdot \sin(\theta)Where:
- \tau is the torque,
- r is the lever arm (distance from the axis of rotation to where force is applied),
- F is the force, and
- \theta is the angle between the force vector and the lever arm.
Importance of the Angle
The angle (\theta ) is vital because it determines how much of the force contributes to rotation. When the force is perpendicular to the lever arm ( \theta = 90^\circ ), \sin(\theta ) is 1, meaning the force gives maximum torque. If the force is parallel to the lever arm ( \theta = 0^\circ ), \sin( \theta ) is 0, and there’s no torque.
The Axis of Rotation
The axis of rotation is the imaginary line around which an object turns. The position of this axis determines how much torque a force will create. Different axes lead to different torque effects. For example, pushing at various points along a baseball bat changes its swings due to altering the axis’s position.
Examples of Different Axes
- A seesaw rotates around its central pivot point.
- A spinning wheel rotates around its central axle.
Lever Arm and Distance
The lever arm is the distance from the axis of rotation to the point where the force is applied. This distance influences torque: greater distances yield more torque for the same force.
Real-life application: A longer spanner makes loosening a tight nut easier because it increases the lever arm length, increasing torque.
Force Diagrams
Understanding force diagrams is crucial to visualizing and calculating torque. These diagrams illustrate the forces acting on an object and their points of application.
Example Problems
Example 1:
A mechanic uses a wrench that is 0.3 meters long to apply a force of 50 Newtons perpendicular to a bolt. Calculate the torque.
Solution:
\tau = r \cdot F \cdot \sin(\theta)Since the force is perpendicular, \theta = 90^\circ , making \sin(90^\circ) = 1 .
\tau = 0.3 \, \mathrm{m} \cdot 50 \, \mathrm{N} \cdot 1 = 15 \, \mathrm{Nm}Practice Problem
A painter applies a force of 40 Newtons to a broom at an angle of 60 degrees from the vertical. The broomstick extends 1.2 meters from the point of rotation. Calculate the torque.
Solution:
\tau = r \cdot F \cdot \sin(\theta) \tau = 1.2 \, \mathrm{m} \cdot 40 \, \mathrm{N} \cdot \sin(60^\circ) = \tau = 1.2 \cdot 40 \cdot 0.866 = 41.57 \, \mathrm{Nm}Conclusion
In AP® Physics 1, torque is essential for analyzing how forces cause rotational motion. Understanding torque, lever arms, and force diagrams helps solve problems involving rotating objects, equilibrium, and angular acceleration.
Study Tips:
- Draw clear free-body diagrams to identify forces and pivot points.
- Practice torque equilibrium problems—look for cases where net torque is zero to solve for unknown forces.
- Use real-world examples like wrenches, seesaws, and doors to visualize how torque works.
- Explore additional resources like AP® Physics 1 practice problems and simulations to reinforce these concepts.
By strengthening your torque problem-solving skills, you’ll be better prepared for AP® Physics 1 multiple-choice and free-response questions!
| Term | Definition |
| Torque \tau | A measure of the force causing an object to rotate. |
| Lever Arm r | The distance from the axis of rotation to the point where force is applied. |
| The Angle \theta | The angle between the force vector and the lever arm. |
| Axis of Rotation | The point or line about which an object rotates. |
